Black Good Thermal Conductive Thermal Conduactivty Graphite Sheet
For Smartphone
Company profile
Ziitek Electronic Material and Technology Ltd. is dedicated to developing composite thermal solution and
manufacturing superior thermal interface materials for competitive
market. Our vast experience allows us to assist our customers best
in thermal engineering field.We serve customers with customized products, full product lines and flexible production, which makes us be the best and reliable partner of you. Let's make
your design more perfect!
Certifications:
ISO9001:2015
ISO14001: 2004 IATF16949:2016
IECQ QC 080000:2017
UL
Products introduction
TIR300C
Series Datasheet-(E).pdf
TIR™380C Series products are a new material with highly effective heat
conductivity and absorption, stabilized device function and reduce
the chance of malfunction by spreading the high temperature heat
radiated from specific parts or devices.
Feature
● Good thermal conductive: 700 W/mK
● used for EMI shielding effect.
● Ultra-thin, light weight, non-toxic and environmentally friendly.
● Low thermal resistance
● RoHS compliant
● UL recognized
● Easy release construction
Application
● PDP,LCD TV,Set top box
● Laptop,Notebook,Projector
● Mobile phone,Hand‐held devices
● Mass storage devices
● Automotive electronics
● Set top boxes
● Audio and video components
| Typical Properties of TIR™300C series |
| Product Name | TIR™340C-T2 | TIR™360-C-T2 | TIR™380-C-T2 | Test Method |
| Colour | Black |
| Material | Cearbon namo composite copper foil vacuum sputtering |
| Total Thickness | 0.040 mm | 0.060 mm | 0.080mm | ASTM D751 |
| Copper foil thickness | 0.038mm | 0.057mm | 0.077mm | ASTM D751 |
| Single-sided coating thickness | 0.0010mm | 0.0015mm | 0.0015mm | ASTM D751 |
| Thickness Tolerance | +/- 10% | +/- 10% | +/- 10% | ASTM D751 |
| Density | 2.7 g/cc | 2.7 g/cc | 2.7 g/cc | ASTM D297 |
| Hardness | 85 Shore A | ASTM D2240 |
| Operation Temperature | -40℃~ 400℃ | ****** |
| Volume Resistivity | 5.2X10³ Ohm-meter | ASTM D257 |
| Tensile Strength | 30psi | 35psi | 40psi | ASTM D412 |
| Typical Thermal Conductivit (In Z axis) | 30W/m-K | 30W/m-K | 30W/m-K | ASTM D5470 |
| Typical Thermal Conductivity (In X-Y axis) | 700W/m-K | 700W/m-K | 700W/m-K | ASTM D5470 |
| Thermal Resistance @100psi | 0.065 (in²℃/W) | 0.079 (in²℃/W) | 0.092 (in²℃/W) | ASTM D5470 |
Standard Sheets Sizes : 500mm x 200m
TIR™ 300C series Individual die cut shapes can be supplied..
Consult the factory alternate thickness
Packaging Details & Lead time
The packaging of Black graphite sheet
1.with PET film or foam-for protection
2. use Paper Card To Separate Each Layer
3. export carton inside and outside
4. meet with customers' requirement-customized
Lead Time :Quantity(Pieces):5000
Est. Time(days): To be negotiated
Why Choose us ?
1.Our value message is'' Do it right the First time, total quality
control''.
2.Our core competencies is thermal conductive interface materials
3.Competitive advantage products.
4.Condidentiality agreement Bussiness Secrect Contract
5.Free sample offer
6.Quality assurance contract
FAQ:
Q: Are you trading company or manufacturer ?
A: We are manufacturer in China.
Q: What's the thermal conductivity test method given on the data
sheet ?
A: All the data in the sheet are actual tested.Hot Disk and ASTM
D5470 are utilized to test the thermal conductivity.
Q: How to find a right thermal conductivity for my applications
A: It depends on the watts of power source , ability of heat
dissipation. Please tell us your detailed applications and the
power, so we can recommend most suitable thermal conductive
materials.
