2.5mmt Silicone Thermal Pad For Automotive Engine Control Units

Ask Lasest Price
Brand Name :	Ziitek
Model Number :	TIF1100-01US thermal pad
Certification :	UL
Price :	0.1-10 USD/PCS
Payment Terms :	T/T
Supply Ability :	100000pcs/month
Delivery Time :	3-8 work days

Add to Cart

Product Details
Company Profile

2.5mmt Silicone Thermal Pad For Automotive Engine Control Units

2.5mmT Easy release construction silicone pads for Automotive engine control units

Company Profile

Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.

TIF100-01US-Series-Datasheet.pdf

Ziitek TIF1100-01US use a special process, with silicone as the base material, adding thermal conductive powder and flame retardant together to make the mixture to become thermal interface material. This is effective in lower the thermal resistance between the heat source and the heat sink.

<Good thermal conductive:1.5 W/mK

<Thickness: 2.5mmT

<Hardness:20 Shore 00

<Colour: Black

<Moldability for complex parts
<Outstanding thermal performance
<High tack surface reduces contact resistance

Applications

<Automotive engine control units
<Telecommunication hardware
<Handheld portable electronics
<Semiconductor automated test equipment (ATE)
<CPU
<display card

Typical Properties of TIFTIF1100-01US
Product Name	TIF1100-01US Series
Colour	Black
Construction & Compostion	Ceramic filled silicone elastomer
Specific gravity	1.9 g/cc
Thickness	2.5mmT
Hardness	20 Shore 00
Dielectric constant@1MHz	2.9 MHz
Continuos Use Temp	-40 to 160℃
Dielectric Breakdown Voltage	>5500 VAC
Thermal conductivity	1.5 W/mK
Volume Resistivity	1.0*10^{12 _Ohm-cm}

Certifications:
ISO9001:2015
ISO14001: 2004 IATF16949:2016
IECQ QC 080000:2017
UL

Ziitek Culture

Quality :
Do it right the first time, total quality control
Effectiveness:
Work precisely and thoroughly for effectiveness
Service:
Quick response, On time delivery and Excellent service
Team work:
Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.

FAQ
Q: How do I request customized samples?
A: To request samples, you can leave us message on website, or just contact us by send email or call us.
Q: What's the thermal conductivity test method given on the data sheet ?
A: All the data in the sheet are actual tested.Hot Disk and ASTM D5470 are utilized to test the thermal conductivity.
