Dielectric Constant 3.9 Mhz Heat Sink Thermal Pad Rohs Compliant Gray For Routers

Ask Lasest Price
Brand Name :	Ziitek
Model Number :	TIF140-10UF thermal pad
Certification :	IATF16949
Price :	0.1-10 USD/PCS
Payment Terms :	T/T
Supply Ability :	100000pcs/month
Delivery Time :	3-8 work days

Add to Cart

Product Details
Company Profile

Dielectric Constant 3.9 Mhz Heat Sink Thermal Pad Rohs Compliant Gray For Routers

Dielectric constant 3.9 MHz RoHS Compliant Gray Heat Sink Pad for Routers

Company Profile

Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.

TIF100-10UF-Datasheet-REV02.pdf

Ziitek TIF140-10UF is not only designed to take advantage of the gap heat transfer, to fill gaps, complete the heat transfer between heating and cooling parts, but also played insulation, damping, sealing and so on, to meet the equipment miniaturization and ultra-thin design Requirements, which is a highly technology and use, and the thickness of the wide range of applications, is also an excellent thermal conductivity filler material.

<Good thermal conductive:1.5 W/mK

<Thickness: 1.0mmT

<Hardness:75 Shore 00

<Colour: Gray

<Easy release construction
<Electrically isolating
<High durability

Applications

<Waterproof LED Power
<SMD LED module
<LED Flesible strip, LED bar
<LED PanelLight
<LED floor light
<Routers

Typical Properties of TIF140-10UF
Product Name	TIF140-10UF Series
Colour	gray
Construction & Compostion	Ceramic filled silicone elastomer
Specific gravity	2.2 g/cc
Thickness	1.0mmT
Hardness	75 Shore 00
Dielectric constant@1MHz	3.9 MHz
Continuos Use Temp	-40 to 160℃
Dielectric Breakdown Voltage	>5500 VAC
Thermal conductivity	1.5 W/mK
Volume Resistivity	1.0*10^{12 _Ohm-cm}

Standard Sheets Sizes:
8" x 16"(203mm x 406mm)

TIF™ series Individual die cut shapes can be supplied.

Why Choose us ?

1.Our value message is'' Do it right the First time, total quality control''.
2.Our core competencies is thermal conductive interface materials
3.Competitive advantage products.
4.Condidentiality agreement Bussiness Secrect Contract
5.Free sample offer
6.Quality assurance contract

FAQ
Q:Do big buyers have promotional prices?
A: Yes, if you are a big buyer in a certain area, Ziitek will provide you with promotional prices, which will help you start your business here. Buyers with long-term cooperation will have better prices.
