4.0mmt Heat Sink Thermal Pad Performance Insulation Silicone For Led Ceiling Lamp

    Buy cheap 4.0mmt Heat Sink Thermal Pad Performance Insulation Silicone For Led Ceiling Lamp from wholesalers

    Buy cheap 4.0mmt Heat Sink Thermal Pad Performance Insulation Silicone For Led Ceiling Lamp from wholesalers
    • Buy cheap 4.0mmt Heat Sink Thermal Pad Performance Insulation Silicone For Led Ceiling Lamp from wholesalers
    • Buy cheap 4.0mmt Heat Sink Thermal Pad Performance Insulation Silicone For Led Ceiling Lamp from wholesalers

    4.0mmt Heat Sink Thermal Pad Performance Insulation Silicone For Led Ceiling Lamp

    Ask Lasest Price
    Brand Name : Ziitek
    Model Number : TIF1160-30-06UF thermal pad
    Certification : UL
    Price : 0.1-10 USD/PCS
    Payment Terms : T/T
    Supply Ability : 100000pcs/month
    Delivery Time : 3-8 work days
    • Product Details
    • Company Profile

    4.0mmt Heat Sink Thermal Pad Performance Insulation Silicone For Led Ceiling Lamp

    4.0mmT Good Performance and Insulation Silicone Pads for LED Ceilinglamp


    Company Profile

    Ziitek Electronic Material and Technology Ltd. is a R&D and production company, we have many production lines and processing technology of thermal conductive materials, owns advanced production equipment and optimized process, can provide various thermal solutions for different applications.


    TIF100-30-06UF-Series-Datasheet-.pdf
    Ziitek TIF1160-30-06UF is recommended for applications that require a minimum amount of pressure on components. The viscoelastic nature of the material also gives excellent low-stress vibration dampening and shock absorbing characteristics. Ziitek TIF1160-30-06UF is an electrically isolating material, which allows its use in applications requiring isolation between heat sinks and high-voltage, bare-leaded devices.


    <Good thermal conductive:3.0 W/mK
    <Thickness: 4.0mmT
    <Hardness:75±5 Shore 00
    <Colour: White

    <Good thermal conductive

    <Moldability for complex parts

    <Soft and compressible for low stress applications


    Applications

    <cooling components to the chassis of frame

    <High speed mass storage drives

    <Heat Sinking Housing at LED-lit BLU in LCD

    <LED TV and LED-lit lamps

    <RDRAM memory modules

    <Micro heat pipe thermal solutions


    Typical Properties of TIF1160-30-06UF
    Product Name

    TIF1160-30-06UF Series

    Colour
    White
    Construction & Compostion
    Ceramic filled silicone elastomer

    Specific gravity

    3.0 g/cc

    Thickness

    4.0mmT
    Hardness
    75±5 Shore 00
    Dielectric constant@1MHz
    5.0 MHz
    Continuos Use Temp
    -40 to 160℃

    Dielectric Breakdown Voltage

    >5500 VAC
    Thermal conductivity
    3.0 W/mK
    Volume Resistivity

    2.3*1013 Ohm-cm


    Standard Sheets Sizes:

    8" x 16"(203mm x 406mm)


    TIF™ series Individual die cut shapes can be supplied.




    Why Choose us ?


    1.Our value message is'' Do it right the First time, total quality control''.

    2.Our core competencies is thermal conductive interface materials

    3.Competitive advantage products.

    4.Condidentiality agreement Bussiness Secrect Contract

    5.Free sample offer

    6.Quality assurance contract




    FAQ

    Q: How do I request customized samples?

    A: To request samples, you can leave us message on website, or just contact us by send email or call us.

    Q: What's the thermal conductivity test method given on the data sheet ?

    A: All the data in the sheet are actual tested.Hot Disk and ASTM D5470 are utilized to test the thermal conductivity.
