Silicone CPU Thermal Pad TIF520-50-11S Grey Color 45shore00 For Mass Storage Devices

Ask Lasest Price
Brand Name :	Ziitek
Model Number :	TIF520-50-11S thermal pad
Certification :	UL
Price :	0.1-10 USD/PCS
Payment Terms :	T/T
Supply Ability :	100000pcs/month
Delivery Time :	3-8 work days

Add to Cart

Product Details
Company Profile

Silicone CPU Thermal Pad TIF520-50-11S Grey Color 45shore00 For Mass Storage Devices

silicone thermal pad and professional CPU thermal pad TIF520-50-11S with grey color 45shore00 for Mass storage devices

Company Profile

With professional R&D capabilities and over 13 year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.

TIF500-50-11S Datasheet-REV02.pdf

TIF520-50-11S Series thermally conductive interface materials are applied to fill the air gaps between the heating elements and the heat dissipation fins or the metal base.Their flexibility and elasticity make them suited to coat very uneven surfaces. Heat can transmit to the metal housing or dissipation plate from the heating elements or even the entire PCB, which effecitly enhances the efficiency and life-time of the heatgenerating electronic components.

Features

Broad range of hardnesses available 5.0 W/mK

Electrically isolating

Outstanding thermal performance

Thickness:0.5mmT

Applications

Mass storage devices

Broad range of hardnesses available

Handheld portable electronics

Audio and video components

Handheld portable electronics

GPS navigation and other portable devices

CD-Rom, DVD-Rom cooling

Typical Properties of TIF520-50-11S
Product Name	TIF520-50-11S Series
Colour	Grey
Construction & Compostion	Ceramic filled silicone rubber
Specific Gravity	3.15 g/cc
Dielectric Constant@1MHz	4.0 MHz
Hardness	45Shore 00
Flame Rating	94 -V0
Continuos Use Temp	-40 to 160℃
Dielectric Breakdown Voltage	>5500 VAC
Thermal conductivity	5.0W/mK
Thickness	0.5mm

Standard Thicknesses:
0.010" (0.25mm) 0.020" (0.51mm) 0.030" (0.76mm) 0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm) 0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm) 0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm) 0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm) 0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm) 0.190" (4.83mm) 0.200" (5.08mm)
Consult the factory alternate thickness.

Standard Sheets Sizes:
8" x 16"(203mm x 406mm) 16" x 18"(406mm x 457mm)
TIF™ series Individual die cut shapes can be supplied.

Peressure Sensitive Adhesive:
Request adhesive on one side with "A1" suffix.
Request adhesive on double side with "A2" suffix.

Reinforcement:
TIF™ series sheets type can add with fiberglass reinforced.

Why Choose us ?

1. Our value message is'' Do it right the First time, total quality control''.

2. Our core competencies is thermal conductive interface materials

3. Competitive advantage products.

4. Condidentiality agreement Bussiness Secrect Contract

5. Free sample offer

6. Quality assurance contract

Ziitek Culture

Quality :

Do it right the first time, total quality control

Effectiveness:

Work precisely and thoroughly for effectiveness

Service:

Quick response, On time delivery and Excellent service

Team work:

Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.

Q: How do I request customized samples?

A: To request samples, you can leave us message on website, or just contact us by send email or call us.
