Soft 3.0W Thermal Conductive Silicone Pad With Various Thermal
Conductivity
Company Profile
Ziitek Electronic Material and Technology Ltd. is dedicated to developing composite thermal solution and
manufacturing superior thermal interface materials for competitive
market. Our vast experience allows us to assist our customers best
in thermal engineering field.We serve customers with customized products, full product lines and flexible production, which makes us be the best and reliable partner of you. Let's make
your design more perfect!
Certifications:
ISO9001:2015
ISO14001: 2004 IATF16949:2016
IECQ QC 080000:2017
UL
TS-TIF®100C 3030-11 series is a silicone-based thermal material designed to fill the
gaps between heat-generating components and liquid cooling plates
or metal bases.lts flexibility and elasticity make it ideal for
covering highly uneven surfaces.With excellent thermal
conductivity, it efficiently transfers heat from heat-generating
elements or PCBs to liquid cooling plates or metal heat dissipation
structures, thereby improving the cooling efficiency of high-power
electronic components and extending the lifespan of the equipment.
Features:
> Excellent thermal conductivity 5.0W/mK
> Self-adhesive without the need for additional surface adhesive
> Highly compressible, soft, and elastic
> Available in various thicknesses
> Good chemical stability
> Easy release construction
> Electrically isolating
> High durability
Applications:
> Cooling components to the chassis of frame
> High speed mass storage drives
> CPU And GPU processors and other chipsets
> Display card
> Mainboard/mother board
> Notebook
> Power supply
> Heat pipe thermal solutions
| Typical Properties of TS-TIF®100C 3030-11 Series |
| Color | Gray | Visual |
| Construction & Compostion | Ceramic filled silicone elastomer | ****** |
| Specific Gravity | 3.1g/cc | ASTM D297 |
| thickness | 0.012"(0.30mm)~0.200"(5.00mm) | ASTM D374 |
| Hardness (thickness＜1.0mm) | 30(Shore 00) | ASTM 2240 |
| Continuos Use Temp | -45 to 200℃ | ****** |
| Dielectric Breakdown Voltage | ≥5500 VAC | ASTM D149 |
| Dielectric Constant | 4.5MHz | ASTM D150 |
| Volume Resistivity | ≥1.0X10¹²Ohm-meter | ASTM D257 |
| Fire rating | 94 V0 | equivalent UL |
| Thermal conductivity | 3.0W/m-K | ASTM D5470 |
Standard Thicknesses:
0.020" (0.51mm) 0.030" (0.76mm)
0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)
0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)
0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)
0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)
0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)
0.190" (4.83mm) 0.200" (5.08mm)
Consult the factory to alternate thickness.
Product Specification
Product Thicknesses: 0.012"(0.30mm)-0.200"(5.00mm)
Product Sizes:8" x 16"(203mm x406mm)
Custom die-cut shapes and thicknesses are available.Please contact
us for details.
Store in a cool, dry place, away from fire and sunlight.
Packaging Details & Lead time
The packaging of thermal pad
1.with PET film or foam-for protection
2. use Paper Card To Separate Each Layer
3. export carton inside and outside
4. meet with customers' requirement-customized
Lead Time :Quantity(Pieces):5000
Est. Time(days): To be negotiated.
